Quick Details
Description
- ype: Filling Machine
- Condition: New
- Application: Powder&Granular Filling
- Packaging Type: Cartons
- Packaging Material: Wood
- Driven Type: Electric
- Voltage: 3P/220V-415V,50/60HZ
- Power: 1-3KW
- Brand Name: TOPSPACK
- Model Number: TP-PF Series
- Dimension(L*W*H): Depend on the type
- Weight: 130-280KG
- Certification: CE,SGS
- Place of Origin: Shanghai,China
- Service: Engineer overseas available
- Filling Weight: 1-5000g
Specifications
1.suitable for powder and granular
2.costomized design
3.SUS 304 meterials
4.touch sreen control system
5.with CE,SGS
A. General description:
1. This filling machine is specially and professionally designed to do dosing and filling work.
2. It is suitable to fill the powders into bottles, cans, jars,and bags. The size of the filling mouth is adjustable according to different containers.
3. It can fill the materials like coffee powder, milk powder, wheat flour, corn flour, rice flour, protein powder, cosmetic powder, chili powder, onion powder , spar powder, chicken powder, gourmet powder, egg powder, washing powder, detegrate powder, talcum powder, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals , powder additive, agriculture pesticide, dyestuff, and so on.
B . Product features:
1. SUS 304 materials,transparent hoper,durable and easy to clean.
2. PLC touch sreen control system,high accuracy and easy to operate.
3. High accuracy online weighting.
4. Servo motor drives screw auger,work stable with high accuracy.
5. Diferent type to choose(auto or semi-auto,one or multi-heads filling).
6. Corollary machines available( mixing machine, feeding machine,sealing machine etc.).
C . Technical parameter:
|
Model
|
TP-PF-A11
|
TP-PF-A21
|
|
Control system
|
PLC & Touch Screen
|
PLC & Touch Screen
|
|
Hopper
|
Quick disconnecting hopper 25L
(enlarged hopper 35L)
|
Quick disconnecting hopper 25L
(enlarged hopper 35L)
|
|
Packing Weight
|
1 - 500g
|
10 - 5000g
|
|
Weight Feedback
|
By off-line scale (in picture)
|
Online weight feedback
|
|
Packing Accuracy
|
≤ 100g, ≤±2%; 100 – 500g, ≤±1%
|
≤ 500g, ≤±1%; >500g, ≤±0.5%
|
|
Filling Speed
|
40 – 120 times per min
|
15 – 40 times per min
|
|
Power Supply
|
3P AC208-415V 50/60Hz
|
3P AC208-415V 50/60Hz
|
|
Total Power
|
0.93 KW
|
1.6 KW
|
|
Total Weight
|
130kg
|
300kg
|
|
Overall Dimensions
|
800×790×1900mm
|
2000×970×2030mm
|
As a professional supplier of packaging machines, we specialized in designing,manufacturing, supporting and sevicing a complete line of machinery for filling and packaging different kinds of liquid,powder and granular, such as water,soda,shampoo,milk powder,honey,milk powder, coffee,white suger, salt, rice, beans and others, etc, which are widely used in agriculture industry,chemical industry, food industry and pharmacy field,etc.
Advanced design concept and professional technique support are always the features of Topspack. Topspack gained a good reputation based on the complete packaging line and excellent careful service as well as the highest machine quality. Our machines have been sold to South and North America, Europe, South and East Asia, and Africa, etc.
Tops group takes orders of professional, faith and reliable as existing concept, therefore we always offer the advanced technique and highest quality machines in packing industry. As we constantly bring forth new ideas, always offer excellent professional service, Topspack is growing stronger and stronger day by day.
Based upon its enterprise spirit TRUST, QUALITY & INOVATION, Tops-Group look forward to providing you with outstanding service and exceptional products!
