Quick Details
Description
- Type: Other
- Condition: New
- Application: Food
- Packaging Type: Stand-up Pouch, Bags
- Packaging Material: Plastic
- Automatic Grade: Automatic
- Driven Type: Electric
- Voltage: 220-380V
- Power: 2KW
- Place of Origin: China (Mainland)
- Brand Name: CHLBAO
- Model Number: CB-4230
- Weight: 540KG
- Dimension(L*W*H): 1080*1300*1400mm
- Certification: CE,SGS,BV
- After-sales Service Provided: Engineers available to service machinery overseas
- Operation video: YES
- Operation manual: YES
- Servo motor: Delta / Taiwan
- PLC touch screen: Siemens /Germany
- Power switch: Schneider/France
- Mid- relay: Omron/Japan
- Solid state relay: YangMing/ Taiwan
- Button switch: Schneider/France
- Residual Current Device switch:Schneider/France
- FRL combination: Airtac/Taiwan
Technical specifications:
|
Model
|
CB-4230
|
|
Bag size
|
L (60-300) ×W (60-200) mm
|
|
Packing speed
|
5-60 bags/min
|
|
Measuring range
|
150-1200 ml
|
|
Max width of film roll
|
≤420 mm
|
|
Air consumption
|
0.65 mpa
|
|
Gas consumption
|
0.3 m3/min
|
|
Power requirement
|
220 V, 50 HZ, 2.2 KW
|
|
Machine size
|
L 1080 * W 1300 * H 1400 mm
|
|
Machine weight
|
540KG
|
Scope of application:
Suit for the quantitative weighing of Popcorn, dry pasta, Meatball, Macaroni, hamburgers, oats, washing powder, puffed food, French Fries, biscuit, rice crust, jelly, candy, pistachio nut, apple flake, dumpling, rice dumpling, chocolate, hardware and medicine such particle, platy, strip and irregular shape,peanut,coffee,small biscuit,granule,puffy food,corn,rice etc..
Function Description:
Adopted to color touch screen and high accuracy output PLC control, bag making, measuring, filling, sealing, date printing, product output in one operation.
The control of pneumatic and power is independent, noise is low, and working is stable.
Adopted to vacuum drawing film, less pulling resistance, bag is formed in better appearance.
Double servo control, high accuracy position with specification size.
Adopted to external film releasing mechanism, simple and easy to install the packaging film.
Adjustment of bag deviation just needed to be played on the touch screen, easy to operate.
Close down machine framework, defending powder into inside of the machine.
