Assembly Line Belt Conveyor System Supplier Offers Custom PVC Belt Conveyor Systems for Assembly Line, Manufacturing Process, Aluminum Alloy Frame, Length 600-5500mm, Width 200-600mm, Anti-static.
- Full unit made with high rigidity alloy aluminum structure beam (A6064)
- A super-strong structure makes it long-wearing and not deformed.
- Convenient to use -- The height of both sides can be adjusted easily by a hand shaft.
- 4 wheels, convenient to move
- 4 fixed feet are foldable, which saves space.
- Adjustable speed, easy to use
- With standard robot connector which can be connected quickly
| Model |
RNA; RNB |
| Belt width (mm) |
200, 300, 400, 500, 600 |
| Conveyor length (mm) |
1500, 2000, 2500, 3000, 3500, 4000, 4500, 5000, 5500, 6000 |
| Plane length (mm) |
300 (W≤300, L≤200), 500 (W≥400, L≤250),700 (W≥600, L≤300) |
| Low-end height (mm) |
700-1000 |
| High-end height (mm) |
1000-1600 |
| Max load (kg) |
25 |
| Leather belt |
PVC, THK 2mm, green, -10℃-80℃, anti-static, wear-resistant, oil-proof |
| Conveyor speed (m/min) |
max: 15 |
| Power supply |
single phase AC220±10V 50/60HZ |
| Power consumption (KVA) |
0.2 |
Runma Robot Company has been staying professional on the manufacture of automatic robots and industrial robots for plastic injection molding plants like:Linear Robot,Cartesian Coordinate Robot,High Speed Robot,Swing Arm Robot,Automatic Disposable Cutlery Packaging System,1-, 2-, 3-, 5-axis robots and customized automation machine in light of customers requirements.Our products are widely applied in plastic injection molding industry.
Runma Robot Manufacturer highly sets store by providing high-qualiity industrial molding robotics and automation products for customers.All the products made from Runma are based on our years of great efforts in R&D,the devotion of skillful team and the most stringent monitoring system.Moreover,Runma Robot provides clients with one-stop service.To kown more or start to choose your plastic injection molding robot
of high quality,Just browse our homepage to choose from:
