Quick Details
Description
Please contact us:chensong@mec.com.cn
1.Double transducer control, flexible bag length cutting, operator needn''t to adjust the unloading working, saving time and saving films.
2.Touchable human-machine operation, convenient and quick parameter setting.
3.Self diagnosis failure function, clear failure display.
4.High sensitivity optical electric color mark tracking and digital input cut position which makes the sealing and cutting more accurate.
5.Separate PID control to temperature, suitable for various packing materials.
6. Reciprocating type sealing device, firmer sealing, no wasting in mold sealing cutter.
7.Terminal sealing device, more beautiful bag shape, improving products level.
8.Stopping the machine in selected position, no sticking to the knife and no waste packing film.
9.Simple driving system, reliable working, convenient maintenance.
10.All the controls are achieved by software, convenient for function adjusting and upgrading.
Usingrange
regular objects such as biscuits,pies,bread,instant noodles,drugs,daily appliances,industrial parts,paper boxes,plates,etc.
Technical parameter
| Model |
JY-450 |
JY-600 |
| Packing speed (bag/minute) |
20-80bag/min |
20-80bag/min |
Packing size (mm)
Length x Width x Height |
L120-450 |
L120-450 |
| W50-210 |
W50-280 |
| H10-120 |
H10-120 |
| Maximum width of film (mm) |
<450mm |
<600mm |
| Thickness of film (mm) |
>0.025mm |
>0.025mm |
| Power |
220V,50/60HZ,3.6KW |
220V,50/60HZ,3.6KW |
| Overall size (mm) |
4380*870*1500mm |
4380*970*1500mm |
| Weight |
950kg |
1160kg |
| Package |
3.1CBM.2CASES |
3.6CBM.2CASES |
| Packing material |
OPP/PP、OPP/CPP、PT/PE、PE、KOP/CPP PT/PE/、AI_/PE etc. Any heat-sealable composite materials foil/film |
JIUYI Machinery Co., Ltd. is located in Yantai Road,Yongqiang Avenue,ETDZ Wenzhou China,Specializing in R&D, design, manufacturing,sales and after-sales services.Our company has developed a variety of different types machines,widely used for food, drinks,paper,metal appliances,and household industries. Especially for the automatic packing machine,sealing machine,filling machine,ice cream machine and bakery equipment.We have applied for many national patents and most have Passed CE certificate,Products well selling in domestic and overseas market,Like:Europe,North America,South America, Central Asia, southeast Asia, Africa etc.
USING HIGHT-TECH BENEFIT FOR CUSTOMERS is our approach.FAST AND THOUGHTFUL AFTER-SALES SERVICE is our principle.we do think what our customers think and we do care what our customers care,give the utmost care and attention for each process of customer consumption.we will continue to improve ourselves,to create our own brand by excellent quality and sincerely service,Let's together towards a more WIN-WIN situation.
