1.Punch the hole on paper in automatic
2.The feeder can fill in more paper
3.can punch more paper in same time
Property:
1. sheet feeding,punching and delivering are all automatic,only oen person is needed to operate,safe and efficient.
2.pile up the sheets by delivery unit without stopping the machine.
3.keep the order of the sheets by convey wheels
4.front guide(push hand) and side guide ensure the consistency and accuracy of punching position.
5.quality gears ensures a smooth operations and low noise level
6.convenient to change and adjust the sheets specification
7.a wide range of optional punching moulds is available.
Usage:
The machine is mainly used to punch holes for bound-books,notebooks,workbooks or calendar.It provides significant increase in productivity and profitability for the users with such advantages as high-speed,accrate-position,high-quality,non-stop working
Major Technical Parameter
Paper thickness: 60g~350g/M2
Max. sheet specification: 360×360mm
Mix. sheet-specification: 140×100mm
Max. sheets-holding thickness per time: 2mm
Max.punching speed: 7000 times/per-hours)
Power: 380V/50HZ
Power of main motor: 2.2KW
Net weight: 1200KG
