Quick Details
Description
- Type: Capping Machine
- Condition: New
- Application: Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
- Driven Type: Electric
- Automatic Grade: Automatic
- Voltage: 220 v or 110v
- Power: 1.5kw
- Packaging Type: Bottles
- Packaging Material: Glass, Metal, Paper, Plastic, Wood
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: Oceanpacking
- Model Number: OPF-PC
- Dimension(L*W*H): 1200*1200*1400mm
- Weight: 500kg
- Certification: ISO
- After-sales Service Provided: Overseas third-party support available
- Filling range: 1-200ml(customized)
- Filling heads: 2 heads
- Speed controler: Frequency controller
- Filling precision: less than 1%
- Capping pass rate: bigger than 99%
- Productivity: 10-40bottles/min
- Liquid contacted material: 316L stainless steel
- Other material: 304 stainless steel
- Control system: PLC control
Technical Data:
|
Filling volume
|
1-200ml(customized)
|
|
Filling head/nozzle
|
2
|
|
Production capacity
|
20-50 bottles/min
|
|
Filling accuracy
|
≤ ±1%
|
|
Capping rate
|
≥99%
|
|
Voltage
|
AC220V/50Hz
|
|
Power
|
1.5KW
|
|
Air requirement
|
50L
|
|
Machine dimension
|
1200mm×1200mm×1400mm
|
Feature:
1. Filling, plugging, capping all in one, full automatic, high speed.
2. filling machine equips with 316L stainless steel plunger pump, suitable to fill
liquid with various viscosity
3. Pump can be easily removed, easy to clean and sterilize.
4. The pump material will be changeable according to the filling material and industry, such as silicon rubber, TFE, ceramic, or other materials
5. PLC control system, frequency conversion speed controller, full automatic and high speed
6. Flexible filling volume adjustment, can adjust each nozzle separately or all nozzles wholly
7. suitable to fill & cap different bottles with various specification, easy to change bottles in very short time
8. designs according to GMP standard
9. Widely used in cosmetic, drinks, chemical, medical, food industry etc, which can highly improve productivity and product quality.
Application:
1) can fill various liquids such as eliquid, essential oil, eyedrop, edible oil, juice, perfume, ink, water, etc for bottles, jars, vials, etc
2) Widely used in cosmetic, drinks, chemical, medical, food industry etc, which can highly improve productivity and product quality.
Guangdong Oceanpacking Co., Ltd (Guangzhou Xunkai Machinery Co., Ltd) is a leading company in packing machine industry. We produce various packing machines, including filling machines, labeling machines, sealing machines, capping machines, coding machines, shrink machines and so on.
Relying on professional technology, excellent services, innovative concept and practical attitude, we specialize in producing and marketing all kinds of packing machines. If you have any questions about our products or services, please do not hesitate to contact us.
