1.The general size: 1160 * 1800 * 2300mm (minimum size specifications) (can be customized)
2.Technical Parameters
1)Material and configuration: box body (panel, within the board, within the roof, outside the station board, door frame) with 1.0mm thick 304 stainless steel plate production (laminating drawing board), the inner channel floor with 3.0mm thick 304 stainless steel anti- The base is 50 * 50 stainless steel square tube, thick 1.5mm. The internal bellows, duct material is moisture resistant, corrosion resistant FRP, good sealing performance. The internal use of bellows, duct, duct air supply, so that the air shower noise greatly reduced, and uniform wind speed.
2)Number of spray balls:No less than 20 per meter, made of stainless steel, both sides and the top three hair, nozzle embedded installation, nozzle blowing direction adjustable.
3)Blowing speed: 22-28m / s
4)Blowing time: 0 - 99s (electronically adjustable)
5)Power: 750W / 380V (single fan)
6)Filtration efficiency: early effect, effective and efficient. Filtration efficiency; dust particle size 0.3um dust removal rate ≧ 99.99 ℅ (sodium flame method), blowing principle: filter - centrifugal fan - static pressure bellows - air duct - sub-duct - nozzle efficient discharge - wind.
7)Noise: ≤ 65dB (air shower outside the 1.5 meters measurement results)
8)Fan: the use of high wind pressure, the amount of wind dedicated fan (2 per meter fan). Each fan full pressure ≥ 1200pa, speed 2800 r / min, air volume ≥ 2500m3 / hour, each fan power: 750w.
9)Automatic doors: imported from Japan infrared sensor. 20-46m / s (adjustable) closed door speed 25-46m / s (adjustable), opening time 0-9 seconds (adjustable), manual thrust <50N. Transmission part of the imitation of domestic low-noise two-speed DC motor control drive,
10)Working procedures: plug-in, the staff into the workshop close to the air shower front door, the infrared sensor sensor air shower front door automatically open, the staff into the air shower after the front door automatically shut down, the internal lighting lights, blowing at the same time; 8 seconds (time adjustable) to complete the blowing shower, the internal stop working, the back door automatically open, the staff into the workshop. Straight-through: When you meet the peak of work, you can open the air shower door and go out at the same time, and blowing work, employees can directly blow into the production workshop, can shorten the staff into the workshop time.
11)Electrical system: Waterproof rating ≧ IP65. (Accessories using well-known brands Germany West, a digital relay, contactors, circuit breakers, converter ST3PF delay relay.
12)Use of the environment: the temperature -20 degrees to 40 degrees humidity is not greater than 90% under normal conditions of operation, the normal life of more than 5 years.
