Carry out the design using the modulation and the hypothesized technique of manufacture, optimize the product structure pattern, the spare parts have high level of “ the standadization, the universalization, the seriation”.
Strength of key parts is calculated with the finite element analysis, the property is stable, the reliability is high.
The structure is reasonable, work smooth, low noise, the operation maintenance is convenient.
In the reducer use the symmetrical divergence type double circular arc or the involute double helical gear transmission, its seal is good, the noise is low, the revolution is steedy, it is reliable and durable.
The beam is H-beam steel structure, which has high strength, good rigidity, large carrying capacity.
The horse head is hanging structure, when carrying out workover, the horse head will be unloaded off.
Support is a three-legged structure, convenient in installation, simple operation.
