Quick Details
Description
35KV grade S11,SZ11,SFZ11 series products are designed in compliance to IEC60076 and GB1094 “ Power Transformer” and GB/T6451 “Technical Parameters and Requirements for Three-phases Oil-immersed Power Transformers”. The load voltage regulation range covers 35±2*2.5%kV, 35±3*2.5%kv,38.5±3*2.5%kV. The voltage can be regulated manually, electrically or automatically in the specified range by using the load regulation switch on the primary side, so as to guarantee the stability of output voltage. Table-flap type tank is adopted in 35KV transformer of 6300KVA and over, so as to improve the mechanic strength, reduce welding work and provide better appearance. The products are widely used and got good operation economy.
Structural
Fully mitered joints are adopted to change the direction of magnetic, diminish the internal flux saturated phenomenon at the core,so as to deduce the no-load loss, no-load current and noise.
To improve the capacity of withstanding short-circuit, drawing plate are adopted for core to make the core into a complete by fixing several nails and connecting through supporter. In addition, Core column paints special silicon rubber to connect all core plates. High-intensity electrical laminated wood installed between the lower part of active part and tank sides to make sure safety and reliable during operate.
Zhejiang Xugao Electric Co., Ltd is a high-tech professional manufacturer of HV Circuit breaker,Disconnector,Power transformer, Current transformer, Composite Insulator, Zinc Oxide Surge Arrester, Fuse Cutout,switchgear and controlgear,parking system,gargae door and openers. The company is also a distributor of other products, such as relays, high-frequency switching power supply, power line carrier,disturbance recorder,relay protection devices.
Our company, basing itself upon high starting-point, high quality, high Level, carries out ISO9001 Quality Management System comprehensively, have established complete Quality Quarantee System. Our company have advanced Research and Development, Test, Production machines and also have a strong engineering technology team which establishe the steady foundation of guaranteeing the quality of our products.
And the electric products comform to IEC61109, IEC60099-4, IEC600282-2, 291, 644, 787and Chinese national standards such as GB/T16927.1, GB/T8952 GB/T15166\15166.3 standards. Some products are CE and KEMA certified.
Based on the double drive strategy at home and abroad, the company consolidates the leading position in the domestic market, and at the same time formulates a long-term development strategy, expands overseas market, and considerably increases the proportion of overseas business.By introducing and training international high-end talents, the company has built an international team with global view, high professional level and excellent foreign language proficiency. The products of the company have been sold to South America, Africa, Middle East, Southeast Asia, etc.
"Zhejiang Xugao Electric" shares brilliant future with you together.
Main Products:
HV Circuit breaker,Disconnector,Power transformer, Current transformer, Composite Insulator, Zinc Oxide Surge Arrester, Fuse Cutout,switchgear and controlgear,parking system (parking equipment),gargae door and openers. The company is also a distributor of other products, such as relays, high-frequency switching power supply, power line carrier,disturbance recorder,relay protection devices
