Quick Details
Description
Type: Other
Condition: New
Application: Chemical, Commodity, Food, Machinery & Hardware, Medical, curd,sauce,chili sauce,soy sauce,salad sauce packing machine, curd,sauce,liquid,oil,milk
Packaging Type: Bags, Film, Pouch, pillow bag,stick sachet,3 side/4side sealing,sachet packing machine
Packaging Material: Plastic, plastic film,paper film,aluminizer film,pur aluminum film
Automatic Grade: Automatic
Driven Type: Electric
Voltage: 220V
Power: 1.2KW
Place of Origin: Guangdong, China (Mainland)
Brand Name: Foshan Kinghanlong packing machinery manufacture CO .,LTD
Model Number: KL-160YS
Weight: 220kg
Dimension(L*W*H): (L)2200*(W)1580*(H)1450mm
Certification: CE SGS
After-sales Service Provided: Engineers available to service machinery overseas
Product name: automatic curd sauce pouch packing machine
Region: Foshan,Guangdong,China supply
Function: automatic counting/feeding/packing/sealing
Packing material: Laminated Film,plastic film
Machine material: 304 Stainless Steel
Packing speed: 30-80 bags/min
selling point: high packing speed/wholesale price/low price/good quality
packing capacity: 1-60ml
warranty: 1 year
Machine characteristics
1. More than 20 languages can be chose,parameter and function setting convenient with touch screen.
2.PLC intelligent control system,operation more steady without stopping machine.
3.Frequency converter control and servo motor,suit for packing several diffrent shape material in one bag.
4. Self-diagnose function, all the fault will be display on the screen,easy to maintenance.
5. High sensitivity photoelectric eye color tracing, number input of bag size ,cutting position accurate.
6. Temperature independent PLC control, more suitable for packing different materials.
7. Positioned stop function, without sticking knife or wasting film.
8. Simple driving system, reliable working, convenient maintenance.
90. All control is realized through solfware, easy for function adjusting and technical updating.
Technical Parameters
|
Machine model
|
KL-160YS
|
KL-100YS
|
|
Bag shape
|
pillow bag/stick sachet/3 side sealing/4 side sealing
|
|
Packing speed
|
10-70bags/min
|
10-60bags/min
|
|
Packing capacity
|
1-500ml
|
1-60ml
|
|
Roll thickness
|
0.05-0.15mm
|
|
Roll diameter
|
Max:300mm
|
|
Roll width
|
30-320mm
|
30-240mm
|
|
Bag width
|
50-150mm
|
30-100mm
|
|
Bag length
|
40-200mm
|
30-150mm
|
|
Power specification
|
220V/50HZ/1.2KW
|
220V/50HZ/1.4KW
|
|
Additional configuration
|
Coding printer/Gas-filled device/Bag connecting device/punch device/Easy to tear gap device
|
Proccess many years of exporting experience,Kinghanlong design and produce in international quantity. Our company produce automatic packing machines,granules packing machines,liquid packing machines,pillow packing machines,food packing machines,powder packing machines .We are specizled in developing ,manufacturing,saling and serving.We focus on exploring self-owned brand.We have passed the CE certification at present. Packing machines extensive use in catering,food,medical,metal,machines,chemical,commodity,agricultural products,art work etc.Our products have sold to more than 30 countries and regions,such as Germany,Holland,France,Russia,Poland etc in Europe.American,Canada, Mexico,Peru,Argentina etc in America.South Africa ,Nigera,Ghana,Egypt etc in Africa ,Southeast Asia and Middle East.
With the development continusly,the factory covers an area of 10000 square meters with 30 enginners,more than 10 designing teams and 200 staff.Our service orriented good faith and high quanlity innnovation,providing the best advance technical and the best services.Welcome clients all over the world to our company!
